Overview
Project No. :
#1522
Project Type :
EVCS Level 2
Location :
New Jersey
Project Description
The installation includes three (3) BTC Power dual-pedestal Level 2 EV chargers, each operating at 208/240V with a 30-80A output and SAE J1772 connectors. Dedicated 40-100A branch circuits will be provided per charger, following NEC 2020 standards for wiring, grounding, and overcurrent protection. The chargers will be integrated with an OCPP 1.6/2.0 backend system, enabling remote monitoring and load management via Wi-Fi, Ethernet, or 4G LTE. Site preparation will include ADA-compliant concrete foundations and coordination with the utility for power availability. Post-installation, commissioning and functional testing will be performed to ensure compliance and optimal operation.
